The Hager RCBO Range, designed for electrical safety in both commercial and domestic settings. This single pole, single module RCBO boasts a 10kA breaking capacity and 30mA residual current sensitivity, providing both overcurrent and fault protection in one compact unit. Available with an ampage range from 6a- 45a, select your option from the dropdown menu.
Architecture
- Neutral position: right
- Number of poles: 1 P
- Type of pole: 1 P
- Fixing mode: DIN rail type O (symmetrical)
- Curve: B
Main electrical features
- Rated operational voltage Ue: 230 / 240 V
- Frequency: 50/60 Hz
- Type of supply voltage: AC
Voltage
- Rated insulation voltage: 250 V
- Rated impulse withstand voltage: 4000 V
Electric current
- Rated residual operating current: 30 mA
Electric current/temperature
- Rating current 30°C: 6 A - 45 A
Dimensions
- Depth of installed product: 70 mm
- Height of installed product: 115 mm
- Width of installed product: 17.8 mm
Power
- Total power loss under IN: 2 W
Endurance
- Electric endurance in number of cycles: 2000
- Number of mechanical operations: 10000
Equipment
- Quick connect: no
- Can be accessorized: No
Standards
- Standard text: BS 61009-1 ; EN 61009-1
- European directive WEEE: concerned
Safety
- Protection index IP: IP20
- Residual current type: A
Use conditions
- Operating temperature: -25…40 °C
